Mato MTS-1202R 500m Prismless Total Station 2'' Accuracy Dual Axis LCD Surveying Instrument

Measure directly to any surface — walls, rocks, buildings — up to 500 meters without a reflector prism. Extended range of 3km (single prism) and 5km (triple prism) for long-distance control surveys.

Incremental photoelectronic encoder with dual horizontal and vertical detection delivers consistent 2-second precision. Minimum readout selectable at 1'' or 5''.

Erect image optical system with 45mm effective aperture and 4'' resolving power. 1°30' field of view with 1.5m minimum focusing distance for sharp target acquisition even in low light.

Liquid-electric detection with plate level technology. ±3' automatic compensation range with 1'' resolution ensures level accuracy on uneven terrain and slopes.

Large, high-contrast LCD panels on both instrument faces allow convenient data reading from any working angle without repositioning.

Fine mode delivers results in just 1.8 seconds (2.5s for first measurement). Tracking mode operates at 0.4 seconds for dynamic target monitoring.

Standard RS-232 serial interface for seamless connection to external data collectors, field controllers, and survey software for efficient post-processing.

Selectable ft or m distance units. Built-in atmospheric correction for temperature (°C/°F), pressure (hPa/mmHg/inHg), earth curvature, and prism constant (0mm / -30mm).

Every MTS-1202R undergoes rigorous multi-point calibration and field simulation testing before shipment, ensuring out-of-box accuracy that meets or exceeds published specifications.

Mato instruments are deployed across construction, engineering, and land surveying projects in over 30 countries, trusted by surveyors, engineers, and contractors worldwide.

Orders ship within 3 working days after payment confirmation. Each instrument is packed in original factory packaging with high-density foam cushioning and export-grade corrugated cartons.

Get survey-grade 2'' accuracy at a fraction of the cost of comparable brands. Flexible payment via T/T, L/C, Western Union, or PayPal for your convenience.

Comprehensive user manuals, online technical assistance, and readily available spare parts. We stand behind every instrument we sell with responsive post-purchase support.
